To complement our range of Networking racks, we also offer a range of IP cabinets. This range is designed to provide ingress protection to the equipment installed inside the cabinet. The cabinets are equipped with air filters as well to prevent dust and pollen.
Manufactured in Galvanised steel, our IP rated cabinets are extremely resistant to rust. They offer extreme rust protection. The internal configuration 19 inch mounting profile and side rails to mount equipment anywhere you like within the cabinet. A suggested 100mm plinth with cable entry provisions is standard with every cabinet.
Typical application
Enclosure features
Eterna Advantage
Data Range
SPECIFICATION AND ORDERING CHART
| Product Code | U Height | Width (mm) | Depth (mm) |
|---|---|---|---|
| EGS-IP-2766 | 27 | 600 | 600 |
| EGS-IP-2788 | 27 | 800 | 800 |
| EGS-IP-27810 | 27 | 800 | 1000 |
| EGS-IP-4268 | 42 | 600 | 800 |
| EGS-IP-42610 | 42 | 600 | 1000 |
| EGS-IP-4286 | 42 | 800 | 600 |
| EGS-IP-4288 | 42 | 800 | 800 |
| EGS-IP-42810 | 42 | 800 | 1000 |
| EGS-IP-4768 | 47 | 600 | 800 |
| EGS-IP-47610 | 47 | 600 | 1000 |
| EGS-IP-4786 | 47 | 800 | 600 |
| EGS-IP-4788 | 47 | 800 | 800 |
| EGS-IP-47810 | 47 | 800 | 1000 |
| 0 | No Protection | No Protection |
|---|---|---|
| 1 | Protected against solid objects over 50mm e.g., hands, large tools | Protected against vertically falling drops of water or condensation |
| 2 | Protection against solid objects over 12.5mm | Protected against falling drops of water, if the case is disposed up to 15mm from vertical |
| 3 | Protected against solid objects over 2.5mm | Protected against sprays of water from any direction even if the case is disposed up to 60mm from vertical |
| 4 | Protected against solid objects over 1.0mm (e.g., wires) | Protected against splash water from any direction |
| 5 | Limited protection against dust ingress (harmful deposits) | Protected against low-pressure water jets from any direction (limited ingress permitted) |
| 6 | Totally protected against dust ingress | Protected against high-pressure water jets from any direction (limited ingress permitted) |
| 7 | N/A | Protected against short periods of immersion in water |
| 8 | N/A | Protected against long durable periods of immersion in water |
